13 Reproducibility

Learning Objectives

By the end of this lesson, you will be able to:

Explain why reproducibility matters in data science
Identify key components of a reproducible workflow
Implement best practices for documentation
Organize project files effectively

1 Why Reproducibility Matters

Reproducibility is a cornerstone of scientific research and data analysis. It ensures that your findings can be verified, your methods can be understood, and your work can be built upon by others (including your future self!).

Definition

Reproducibility means that your analysis can be recreated by others using the same data and methods, producing the same results.

In practice, reproducibility provides several key benefits:

Verification: Others can confirm your findings
Collaboration: Team members can understand and contribute to your work
Efficiency: You can revisit and build upon your own work more easily
Impact: Your research can have greater influence when others can use it
Trust: Reproducible research builds credibility in your findings

2 Components of Reproducible Workflows

A reproducible data science workflow typically includes the following elements:

2.1 Documented Code

# Example of well-documented code
# Purpose: Calculate mean values by group
# Input: data frame with numeric 'value' column and categorical 'group' column
# Output: data frame of group means

calculate_group_means <- function(data, value_col, group_col) {
  # Check inputs
  if (!is.data.frame(data)) {
    stop("Input must be a data frame")
  }

  # Calculate means by group
  result <- aggregate(data[[value_col]], by = list(Group = data[[group_col]]),
                     FUN = mean, na.rm = TRUE)

  # Rename columns for clarity
  names(result)[2] <- "Mean"

  return(result)
}

2.2 Version Control

Version control systems like Git help track changes to your code and files over time. We’ll cover this in detail in a later lesson.

2.3 Environment Management

Documenting your software environment ensures others can recreate the same conditions:

# Example of capturing package versions
sessionInfo()

# Or using the renv package for project-specific environments
# install.packages("renv")
# renv::init()
# renv::snapshot()

2.4 Data Management

Proper data management includes:

Raw data preservation (never modify the original data)
Data cleaning scripts (document all transformations)
Clear data documentation (metadata)

2.5 Clear Documentation

Documentation should include:

Project overview and purpose
Data sources and descriptions
Analysis methods and justification
Instructions for reproducing results

3 File Organization Strategies

An organized file structure makes your project more navigable and reproducible:

project/
├── README.md           # Project overview and instructions
├── data/
│   ├── raw/            # Original, immutable data
│   └── processed/      # Cleaned, transformed data
├── code/
│   ├── 01_clean.R      # Data cleaning script
│   ├── 02_analyze.R    # Analysis script
│   └── 03_visualize.R  # Visualization script
├── results/
│   ├── figures/        # Generated plots
│   └── tables/         # Generated tables
├── docs/
│   └── report.Rmd      # R Markdown report
└── renv/               # Package environment information

Best Practice

Name your files in a way that indicates their order and purpose, such as 01_data_cleaning.R, 02_analysis.R, etc.

4 Documentation Best Practices

Effective documentation should:

Be comprehensive - Include all necessary information
Be clear - Use plain language and avoid jargon
Be current - Update as your project evolves
Be accessible - Store documentation with your project

A good README file typically includes:

Project title and description
Installation and setup instructions
Usage examples
Data dictionary
Analysis workflow overview
Dependencies and requirements

5 Practice Exercises

5.1 Project Evaluation

Evaluate a recent project of yours for reproducibility. Identify three specific improvements you could make to enhance its reproducibility.

Solution: Reproducibility Evaluation

Three specific improvements to enhance reproducibility in a data analysis project:

Version Control Implementation: Set up a Git repository for the project to track changes to code and documentation. This would allow for better tracking of modifications, collaboration with others, and the ability to revert to previous versions if needed.

# Example Git setup commands
# Initialize a Git repository
git init

# Add all files to the repository
git add .

# Make an initial commit
git commit -m "Initial commit of project files"

# Create a remote repository on GitHub and link it
git remote add origin https://github.com/username/project-name.git
git push -u origin main

Environment Documentation: Create a reproducible environment using the renv package to track and manage package dependencies. This ensures that others can recreate the exact same package versions used in the analysis.

# Install and initialize renv
install.packages("renv")
renv::init()

# After installing all required packages, create a snapshot
renv::snapshot()

# Include instructions in README.md for others to restore the environment
# renv::restore()

Data Pipeline Documentation: Create a clear data processing pipeline with numbered script files and documentation of each transformation step. This would make it easier to understand how raw data was processed into the final analysis dataset.

# Example file structure
# 01_data_import.R - Import raw data
# 02_data_cleaning.R - Clean and preprocess data
# 03_analysis.R - Perform main analysis
# 04_visualization.R - Create visualizations

# Example documentation in scripts
#' Data Cleaning Script
#'
#' This script performs the following operations:
#' 1. Removes duplicate records
#' 2. Handles missing values
#' 3. Transforms variables to appropriate types
#' 4. Creates derived variables needed for analysis
#'
#' Input: raw_data.csv
#' Output: clean_data.csv

5.2 File Organization

Create a file organization template for your next data analysis project, following the best practices outlined in this lesson.

Solution: Project Organization Template

Here’s a file organization template for a data analysis project following best practices:

project_name/
├── README.md                 # Project overview, setup instructions, and usage
├── CONTRIBUTING.md           # Guidelines for contributors (if collaborative)
├── LICENSE                   # Project license information
├── .gitignore                # Specifies files to exclude from version control
├── renv/                     # R environment information (created by renv)
├── renv.lock                 # Package dependency snapshot
├── data/
│   ├── raw/                  # Original, immutable data
│   │   ├── dataset1.csv      # Original data files
│   │   └── dataset2.xlsx
│   ├── processed/            # Cleaned, transformed data
│   │   ├── clean_dataset1.csv
│   │   └── analysis_ready.rds
│   └── README.md             # Data dictionary and source information
├── code/
│   ├── 00_setup.R            # Project setup, load packages, set global options
│   ├── 01_import_data.R      # Data import scripts
│   ├── 02_clean_data.R       # Data cleaning and preprocessing
│   ├── 03_explore_data.R     # Exploratory data analysis
│   ├── 04_analyze_data.R     # Main analysis scripts
│   └── 05_visualize_data.R   # Visualization scripts
├── results/
│   ├── figures/              # Generated plots and visualizations
│   │   ├── exploratory/      # Exploratory visualizations
│   │   └── final/            # Publication-ready figures
│   └── tables/               # Generated tables and summaries
├── docs/
│   ├── data_dictionary.md    # Detailed variable descriptions
│   ├── analysis_plan.md      # Pre-specified analysis plan
│   └── methods.md            # Detailed methodological notes
└── reports/
    ├── exploratory_report.Rmd # R Markdown for exploratory analysis
    └── final_report.Rmd       # Final analysis report

Key features of this template: - Clear separation of raw and processed data - Numbered scripts to indicate workflow order - Comprehensive documentation - Version control readiness - Environment management with renv - Separate locations for code, data, results, and documentation

5.3 Function Documentation

Write documentation for a simple R function that you commonly use, following the guidelines for effective code documentation.

Solution: Function Documentation

Here’s an example of well-documented R function for summarizing data:

#' Summarize Numeric Variables by Group
#'
#' This function calculates summary statistics for numeric variables
#' grouped by one or more categorical variables.
#'
#' @param data A data frame containing the variables to summarize
#' @param num_vars Character vector of numeric variable names to summarize
#' @param group_vars Character vector of grouping variable names
#' @param stats Character vector of statistics to calculate.
#'        Options include: "mean", "median", "sd", "min", "max", "n", "se"
#' @param na.rm Logical indicating whether to remove NA values (default: TRUE)
#'
#' @return A data frame with summary statistics for each numeric variable by group
#'
#' @examples
#' # Create example data
#' example_data <- data.frame(
#'   group1 = rep(c("A", "B"), each = 10),
#'   group2 = rep(c("X", "Y"), times = 10),
#'   value1 = rnorm(20, mean = 10, sd = 2),
#'   value2 = runif(20, min = 0, max = 100)
#' )
#'
#' # Summarize one numeric variable by one group
#' summarize_by_group(
#'   data = example_data,
#'   num_vars = "value1",
#'   group_vars = "group1",
#'   stats = c("mean", "sd", "n")
#' )
#'
#' # Summarize multiple numeric variables by multiple groups
#' summarize_by_group(
#'   data = example_data,
#'   num_vars = c("value1", "value2"),
#'   group_vars = c("group1", "group2"),
#'   stats = c("median", "min", "max")
#' )
#'
#' @export
summarize_by_group <- function(data, num_vars, group_vars,
                               stats = c("mean", "sd", "median", "min", "max", "n"),
                               na.rm = TRUE) {
  # Input validation
  if (!is.data.frame(data)) {
    stop("'data' must be a data frame")
  }
  if (!all(num_vars %in% names(data))) {
    stop("Not all numeric variables found in data")
  }
  if (!all(group_vars %in% names(data))) {
    stop("Not all grouping variables found in data")
  }

  # Create grouping formula for aggregate
  group_formula <- as.formula(paste("~", paste(group_vars, collapse = "+")))

  # Initialize results list
  results_list <- list()

  # Calculate standard error function
  se <- function(x, na.rm = TRUE) {
    if (na.rm) x <- x[!is.na(x)]
    sqrt(var(x) / length(x))
  }

  # Process each numeric variable
  for (var in num_vars) {
    # Initialize stats list for this variable
    var_stats <- list()

    # Calculate requested statistics
    if ("mean" %in% stats) {
      var_stats$mean <- aggregate(data[[var]], by = eval(group_formula, data),
                                 FUN = mean, na.rm = na.rm)
    }
    if ("median" %in% stats) {
      var_stats$median <- aggregate(data[[var]], by = eval(group_formula, data),
                                   FUN = median, na.rm = na.rm)
    }
    if ("sd" %in% stats) {
      var_stats$sd <- aggregate(data[[var]], by = eval(group_formula, data),
                               FUN = sd, na.rm = na.rm)
    }
    if ("min" %in% stats) {
      var_stats$min <- aggregate(data[[var]], by = eval(group_formula, data),
                                FUN = min, na.rm = na.rm)
    }
    if ("max" %in% stats) {
      var_stats$max <- aggregate(data[[var]], by = eval(group_formula, data),
                                FUN = max, na.rm = na.rm)
    }
    if ("n" %in% stats) {
      var_stats$n <- aggregate(data[[var]], by = eval(group_formula, data),
                              FUN = function(x) sum(!is.na(x)))
    }
    if ("se" %in% stats) {
      var_stats$se <- aggregate(data[[var]], by = eval(group_formula, data),
                               FUN = se, na.rm = na.rm)
    }

    # Combine all stats for this variable
    var_result <- var_stats[[1]]
    names(var_result)[ncol(var_result)] <- paste0(var, "_", names(var_stats)[1])

    for (i in 2:length(var_stats)) {
      stat_name <- names(var_stats)[i]
      var_result[[paste0(var, "_", stat_name)]] <- var_stats[[i]][, ncol(var_stats[[i]])]
    }

    results_list[[var]] <- var_result
  }

  # Merge results for all variables
  final_result <- results_list[[1]]
  if (length(results_list) > 1) {
    for (i in 2:length(results_list)) {
      final_result <- merge(final_result, results_list[[i]], by = group_vars)
    }
  }

  return(final_result)
}

This documentation follows best practices by including: 1. A clear title and description 2. Detailed parameter descriptions 3. Information about the return value 4. Multiple examples showing different use cases 5. Export tag for package development 6. Input validation within the function 7. Comprehensive comments explaining the code logic
